MEC120 Fireye Chassis

MEC120 Fireye Chassis

$ 97.89
Follow:

Acoustic Benefits

Mid Tones
High Tones
Sound Absorption

Product Features

Pin Able
Easy To Install
Peel And Stick
Customizable
Recycled PET
Locally Made
Acoustic NRC
Quick Ship Item
Overview The Fireye MEC120 is a compact, microprocessor-based modular burner management chassis designed for the MicroM Series Flame Safeguard Control. It provides the foundational platform for automatic ignition sequencing and continuous flame monitoring for commercial and industrial heating and process equipment. Engineered for versatility, it is backward compatible with legacy Fireye TFM, UVM, and M-Series II controls, often allowing for direct interchangeability when paired with appropriate modules. Features Microprocessor-based design for precise timing and dependable operation. Modular architecture allowing for interchangeable plug-in programmer and amplifier modules. Smart diagnostic LEDs for real-time system status and troubleshooting. Backward compatibility with existing Fireye infrastructure to simplify system upgrades. Accessible manual reset button for clearing lockouts following ignition failures. Supports optional alpha-numeric display (ED510) and serial communications via Modbus or E500 interface. Specifications Model Number: MEC120 Supply Voltage: 120 VAC (min. 102, max. 132), 50/60 Hz Power Consumption: 12 VA (Operating) Temperature Range: -40 degrees F to 140 degrees F (-40 degrees C to 60 degrees C) Dimensions: Approximately 5.18 x 5.31 x 5.18 inches Shipping Weight: Approximately 3 lbs (1.4 kg) Approvals: UL listed and FM approved Applications The Fireye MEC120 is used in commercial and industrial combustion systems for burners firing any type of fuel, including natural gas, propane, and light oil. It serves as a central hub for flame safeguard systems in boilers, furnaces, and process heaters where reliable flame supervision and automatic ignition are required. It is an ideal choice for both new installations and retrofitting older burner management systems.
